Subnet mask and gateway should be configured to match those of PC.
The front part of the IP Address and Gateway should match depending on how many
times the number 255 is repeated in the Subnet Mask.
For example, when the subnet mask is 255.255.0.0, IP address can take the form
172.30.XXX.XXX and the gateway will take the form 172.30.YYY.YYY.
If the subnet mask is 255.255.255.0, IP address could take the form 172.30.153.XXX
and the gateway will take the form 172.30.153.YYY.
Each of XXX and YYY is a number in range of 0~255.
Duplicate IP addresses are not allowed.
Select [Apply this new setting] to save changes. A system reboot is required for
changes to be applied.
Select [X] button if you want to modify the setting. Select [OK] if you want to go back
to configuration. In this case, Xpanel should restart.
Download by Ethernet
1) Run Xpanel Designer and open a project to be downloaded.
2) Go to [Online] – [Setup Link].
Project Download
