SECTION 4 SPECIFICATIONS
DIMENSIONS
COMPONENT MODEL
WIDTH
LENGTH HEIGHT WEIGHT
Shipped Installed
In.
(mm)
In.
(mm)
In.
(mm)
In.
(mm)
Lbs.
(kg)
MAIN FRAME
5 X 10 125 189 268 100 23,200
(1.5 X 3.0 m) (3175) (4801) (6808) (2540) (10524)
6 X 12 144 208 268 100 27,200
(2.0 X 4.0 m) (3658) (5283) (6807) (2540) (12338)
8 X 20 160.5 274 414.2 99.1 ?
(2.5 X 6.1 m) (4077) (6960) (10521) (2517) (11135)
LOAD FRAME
5 X 10 84.25 134 40 8,750
(1.5 X 3.0 m) (2140) (3404) (991) (3969)
6 X 12 103 161 40 10,200
(2.0 X 4.0 m) (2616) (4090) (991) (4631)
8 X 20 122.25 270 41 22,900
(2.5 X 6.1 m) (3105) (6858) 41 22,900
CHILLER
CL-920 (60 Hz)
28 50 66 900
(711) (1270) (1677) (409)
CL-940 (60 Hz)
28.5 42 64 1110
(915) (1474) (1626) (544)
CL-960 (60 Hz) 35.5 50 64 1400
CL-980 (60 Hz) 35.5 50 64 1400
SPECIFICATIONS
LASER
RATED
POWER
TYPICAL
RANGE
YLS-2000 2000 W 200-2000 W
YLS-4000 4000 W 400-4000 W
YLS-6000
6000 W 600-6000 W
alta-6000
alta-8000 8000 W 800-8000 W
WAVELENGTH: 1.07 micron
MODE: CW, QCW
LASER: Class IV
MAXIMUM WORKPIECE:
MODEL
WORKPIECE
DIMENSIONS
EVENLY
DISTRIBUTED
LOAD
X Y CAPACITY *
5 X 10
120 in.
(3048 mm)
60 in.
(1524 mm)
2292 lb.
(1134 kg)
6 X 12
157.5 in.
(4000 mm)
78.75 in.
(2000 mm)
3948 lb.
(1588 kg)
8 X 20
240 in.
(6096 mm)
98.5 in.
(2500 mm)
6690 lb.
(3035 kg)
* ACTUAL PROCESSING CAPACITY DEPENDS ON MATERIAL TYPE
