1-1
EM-573 (N-04-18)
SECTION 1 IDENTIFICATION
CINCINNATI CL-900 SERIES LASER SYSTEM - FIBER LASER
1. ENCLOSURE
2. OPERATOR DOOR
3. LASER STATUS INDICATOR LIGHT
4. MATERIAL SUPPORTS
5. MATERIAL CLAMPS
6. UPPER PALLET
7. BALL TRANSFER REMOTE (OPT)
8. E-STOP BUTTON
9. LOAD FRAME
10. PALLET DOOR
11. SCRAP BIN ACCESS DOOR
12. OPERATOR CONTROL STATION
13. MAIN FRAME
14. CONTROL ENCLOSURE
15. POWER ENCLOSURE
Figure 1-1 Front View
4
5
6
1 2
3
7
8
9
10
11
12
13
15
14
