14
8000 Series Mobile Computer Reference Manual
1.5 NOTIFICATIONS
1.5.1 STATUS LED
The dual-color LED above the screen is used to provide information on the charging
status and can be programmed to provide information that helps diagnosing. For
example, if you are using AG Runtime, you will be informed of the scanning result
immediately. The green LED is used for "Good Read" upon reading a barcode
successfully.
LED: Red/Green Red Green
Charging 8000 On ---
Charging done --- On
Good Read --- On
Error occurs On ---
1.5.2 AUDIO
The mobile computer has a low power transducer type buzzer, which can be programmed
for status feedback. In particular, its frequency and duration are software programmable
for Good Read in the provided terminal emulation programs.
