40
8000 Series Mobile Computer Reference Manual
3.7.2 CONNECTION SET
DialUp Number
Enter the number provided by your ISP.
Login Name
Enter the login name provided by your ISP.
Login Password
Enter the login password provided by your ISP.
Baud Rate
Select a desired baud rate.
Note: By default, the baud rate is set to 57600 bps on the Modem Cradle.
For any other value, such as 115200/38400/19200/9600, you must configure
through the DIP switch on the IR control board.
3.7.3 ECHO TEST
This echo test is used for verifying connectivity via Point-to-Point Protocol. For the
Modem Cradle, its physical connectivity can be verified in System Menu | Tests | Echo
Test | IR or MODEM.
Note: Enter the IP address of a server with which a PPP connection is desired. Then, it
will try to connect to the server. After the PPP connection is established properly,
run the utility “EchoTest.exe” on your computer (TCP/IP – Server), and then, start
this test on your mobile computer.
