CIPU CSPPS702 - Illustrated Parts List

ILLUSTRATED PARTS LIST
Ref.No. Part. No. Description QTY Remark
1 647284871 Cover 1
2 65431042080 O-Ring 1
3 647252704 Basket 1
4 647284801 Pump Housing 1
5 647252705 Clip 1
6 65431029080 O-Ring 1
7 65221002000 Screw M5*30 8
8 647284802 Pump Cover 1
9b 647272971000 Impeller For CSPPS702 1
9c 647252771000 Impeller For CSPPS703 1
10 65431044080 O-Ring 1
11 65028003000 Seal Assembly 1
12 647284803 Pump Housing 1
13 647284804 Motor Mounting Plate 1
14 65231016106 Nut M5 8
15b 65023402000 1.0HP Motor For CSPPS702 1
15c 65023403000 1.5HP Motor For CSPPS703 1
16 65432002080 Drain Plug Gasket 1
17 648860105 Drain Plug 1
18 647202702 Adaptor 1
19 91382005 1.5’’ Adaptor Assembly 2
