Circor IMO 3E Series User Manual

A
A
SECTION A-A
4
12
11
13
6
27
26
16
1
7
8
8
2
3
5
TORQUE TO
170
u 10 LB IN
TORQUE TO
170
u 10 LB IN
TORQUE TO
75
u 5 LB IN
INLET
OUTLET
ASSEMBLE PUMP SO THAT END
OF IDLER WITH ROOT TAPER IS
AT INLET END OF PUMP
NOTES:
1. DRAIN HOLE IN COVER IDP #4 TO BE ASSEMBLED
IN THE DOWN POSITION.
B B
SECTION B-B
15
92
93
96
97
76
75
FIGURE 10 - STEEL CASED D3EJ(N)CS - C-FACE MOUNTING
