1 96 97 4 27 12
6
7
13
9293
26
7576523 8 16
TORQUE TO 131±10 LB IN
TORQUE TO
35±2 LB IN
TORQUE TO 131±10 LB IN
OUTLETINLET
NOTES:
1. DRAIN HOLE IN COVER (IDP 4 & 92)
TO BE ASSEMBLED IN THE DOWN
POSITION
SEE NOTE #1
11
15
ASSEMBLE PUMP SO THAT END OF
IDLER WITH ROOT TAPER IS AT
INLET END OF PUMP
FIGURE 11 - STEEL CASED D3EJ(N)FS - FOOT MOUNT PUMP
