set
Pa r i
no
Figure 57. Parity
4.2.5 Data bits
7 or 8 data bits may be selected; to select the number of bits, press the
max
key
and the two options will alternate in turn. Once the required option is selected,
press the
key to enter the data and access the next setting step.
Figure 58. Data bits
4.2.6 Stop bits
1 or 2 stop bits may be selected; to select the number of bits, press the
max
key
and the two options will alternate in turn. Once the required option is selected,
press the
key to enter the data and access the next setting step.
set
st op
1
Figure 59. Stop bits
4.2.7 Protection of data Set-up using password
This menu option aims to protect the data set in Measurement Set-up.
As a default the equipment does NOT protect data with the “unlo” option. By
pressing the
key the data is entered and setting the equipment is finalised.
If, on the other hand, the parameters in Measurement Set-up are to be protected,
the option “Loc” has to be selected using the
max
key and then the key
pressed. The protection password as a default will always be 1234; any other
password code entered will be incorrect.
set
pass
0000
set
pass
1234
Figure 60. Password request to
protect Set-up data
Figure 61. Enter password to protect
Set-up data
For entering the password, repeatedly press the
max
key increasing the value of
the digit which is flashing at the time.
