Page 23 of 26
6 MODBUS RTU PROTOCOL
The CVM-MINI power analyzer communicates using the MODBUS© protocol. In the
MODBUS protocol the RTU (Remote terminal Unit) mode is used; each 8-bit per byte
in a message contains two 4-bits hexadecimal characters.
The format for each byte in RTU mode is:
Code 8 bit binary, hexadecimal 0-9, A-F.
2 hexadecimal characters contained in each 8-bit field in
the message.
Bits per byte 8 data bits.
Field Check-Error CRC Type (Cyclical Redundancy Check).
Modbus functions used:
Function 01 Reading the status of the relays.
Function 03 and 04 Reading n Words (16 bits-2 bytes). Function used for
reading the electrical parameters that the CVM-MINI is
measuring. All electrical parameters are long with 32 bits,
because of this two Words are required to request each
parameter.
(4 bytes - XX XX XX XX)
Function 05 Writing a relay.
6.1 MODBUS memory map
PARAMETER
SYMBOL
Instant
Maximum
Minimum
Units
Voltage phase
V L1
00-01
60-61
C0-C1
V x10
Current
A L1
02-03
62-63
C2-C3
mA
Active power
kW L1
04-05
64-65
C4-C5
w
Reactive power
Kvar L1
06-07
66-67
C6-C7
w
Apparent power
kV·A L1
4A-4B
AA-AB
10A-10B
Power factor
PF L1
08-09
68-69
C8-C9
x 100
Voltage phase
V L2
0A-0B
6A-6B
CA-CB
V x10
Current
A L2
0C-0D
6C-6D
CC-CD
mA
Active power
kW L2
0E-0F
6E-6F
CE-CF
w
Reactive power
Kvar L2
10-11
70-71
D0-D1
w
Apparent power
kV·A L2
4C-4D
AC-AD
10C-10D
w
Power factor
PF L2
12-13
72-73
D2-D3
x 100
Voltage phase
V L3
14-15
74-75
D4-D5
V x10
Current
A L3
16-17
76-77
D6-D7
mA
Active power
kW L3
18-19
78-79
D8-D9
W
Reactive power
Kvar L3
1A-1B
7A-7B
DA-DB
W
Apparent power
kV·A L3
4E-4F
AE-AF
10E-10F
w
Power factor
PF L3
1C-1D
7C-7D
DC-DD
x 100
Temperature
ºC
50-51
B0-B1
110-111
ºC x 10
