5.6.- CONNECTING THE CURRENT CIRCUIT
ENSURE THAT THE SELECTOR (ON-OFF-ON) ON THE
MPC-20 & MPC-50 IS DISCONNECTED AND WITHOUT THE KEY.
Connect the "OUTPUT CABLES": to the ground to be measured and the
other to the auxiliary ground.
5.7.- CONNECTING THE POWER SUPPLY
5.7.1.- POWER SUPPLY FOR THE MPC-20:
Connect the supply cable to a 230 V II+TT system or an independent
generator with the same VOLTAGE.
5.7.2.- POWER SUPPLY FOR THE MPC-50:
Connect the supply cable to a 400 V II+TT system or an independent
generator with the same VOLTAGE (As an exception the MPC-50 may be
connected to 230 V).
