--- MPC 20 & 50 TESTER - M-981136 (vers. BD) --- Page
20
READ TESTED VOLTAGE (V) on the display.
Note: If the read out on the display is less than 30 V the internal scale is
automatically changed to 30 V AC.
DISENGAGE THE OPERATION SELECTOR. Once the test has
finished the values remain displayed until the key is turned again, the
equipment is switched off or the Imax value is set again.
5.12.- TEST RESULTS (THAT WILL REMAIN DISPLAYED)
Real current Maximum current
of the test made
Im. NN,N I x. NNNN
default theory
Voltage tested
during the test
Vm. NN,N V NNNNN
Calculated voltage
default theory
(step or touch)
Vm x Ix
STEP VOLTAGE (Vp) : V = --------------------
Im
Vm x Ix
TOUCH VOLTAGE (Vc) : V = ---------------------
Im
