Page #34 background image
24-30
Page 34
Serials w/ MCU 16600-001
EFFECTIVITY:
CIRRUS AIRPLANE MAINTENANCE MANUAL MODELS SR22 AND SR22T
01 Jan 2012
H. MCU Bottom Cover - Serials w/ MCU 16600-001 (See Figure 24-307)
(1) Removal - MCU Bottom Cover
(a) Remove MCU cover. (Refer to 24-30)
(b) Remove nuts, washers, and clamps securing wire harness loom to chassis.
Note: Label cable guide routing holes with wire harness name to facilitate re-
installation.
(c) Remove screws and washers securing cable guide to chassis.
(d) Remove screws securing MCU bottom cover to chassis. Remove MCU bottom cover from
chassis.
(2) Installation - MCU Bottom Cover
(a) Position MCU bottom cover to chassis and secure with screws.
(b) Position cable guide around wire harness J108, J109, J111, J115, and J757, if installed.
(c) Install screws and washers securing cable guide to chassis.
(d) Position wire harness loom to chassis and secure with clamps, washers, and nuts.
(e) Install MCU cover. (Refer to 24-30)
