M. Logic Module - Serials w/ MCU 14600-001, 14600-002, & 16600-001 (See Figure 24-307)
The logic module, integral to the MCU, is centrally located on the power board assembly.
(1) Removal - Logic Module
(a) Set BAT 1, BAT 2, and AVIONICS switches to OFF positions.
(b) Remove engine cowling. (Refer to 71-10)
(c) Disconnect battery 1. (Refer to 24-30)
(d) Remove MCU cover. (Refer to 24-30)
(e) Remove screws and washers securing logic module to power board assembly.
(f) Remove logic module from power board assembly.
(2) Installation - Logic Module
CAUTION: Before installing, examine logic module for bent pins. If bent pins are found, gently
straighten them.
Do not force logic module into power board jack. Logic module should install into
jack with gentle pressure.
(a) Align logic module pins to power board jack and gently press logic module onto power
board.
(b) Install screws and washers securing logic module to power board assembly.
(c) Install MCU cover. (Refer to 24-30)
(d) Connect battery 1. (Refer to 24-30)
(e) Perform Operational Inspection - Master Control Unit. (Refer to 24-30)
(f) Install engine cowling. (Refer to 71-10)
