12 Checking the Access Point LEDs
Access Point Status LEDs
The location of the access point status LED is shown in Figure 1.
Note Regarding LED status colors, it is expected that there will be small variations in color intensity
and hue from unit to unit. This is within the normal range of the LED manufacturer’s
specifications and is not a defect.
The access point status LED indicates various conditions and are described in Table 2.
Table 2 LED Status Indications
Message
Type
LED State Message
Meaning
Association status Chirping Green Normal operating condition, but no wireless
client associated
Green Normal operating condition, at least one wireless
client association
Boot loader status Green Executing boot loader
Boot loader error Red Boot loader signing verification failure
Access point regulatory
domain priming status
Blinking Amber AP priming to a new regulatory domain by
Neighbor Discovery Protocol (NDP), in progress
Cycling Red, Green and
off
AP waiting to be primed
Chirping Red AP primed to a wrong regulatory domain
