Cisco 2500 Series Installing Guide

4 Installing Cisco AC and DC Power Supplies in Cisco 2500 Series Routers
Removing AC and DC Power Supplies
Figure 2 Removing the Screw
Step 2
Disconnect the power connector from the system board. (See Figure 3.) Grasp the sides
of the power connector and pull upward while rocking the connector side to side.
Caution Do not pull on the connector wires.
Figure 3 Disconnecting the Power Connector
Step 3
Push the loosened power supply backward and lift it out of the chassis. (See Figure 4.)
H9079
Input: 100-240VAC
Freq: 50/60 Hz
Current: 1.2-0.6A
Watts: 40W
0
1
Screw
H9081
Power connector
Fan connector
Fan
AC power supply
