Cisco 2800 Series Quick Start Guide

21
Connecting the Router to DC Power
If your router has a DC-input power supply, follow the directions in this section for proper wiring. If backup power is required,
see the “Connecting the Router to Backup Power” section on page 26.
Note Cisco 2801 routers are not designed to connect to DC power.
DC Wiring Requirements for Cisco 2800 Series Routers
Caution DC return is isolated from the frame (NEBS DC-I).
Warning This product requires short-circuit (overcurrent) protection, to be provided as part of the building installation.
Install only in accordance with national and local wiring regulations. Statement 1045
Warning This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the
protective device is rated not greater than:
60 VDC, 20 A. Statement 1005
Warning Use copper conductors only. Statement 1025
Note The DC-input power supply does not apply to Cisco 2801 router.
A Cisco 2800 series integrated services router with a DC-input power supply requires copper wire for the power connections.
Table 1 and Table 2 summarize the wiring requirements.
You can connect a single DC power source to either the A input or the B input. If there are dual power sources, connect one
source to the A input and one source to the B input. Both sources must be the same polarity and voltage.
Table 1 DC Wiring Requirements for Cisco 2811 Routers
DC Input DC Input Wire Size
Safety Ground Wire
Size Wire Terminal (Lug)
Overcurrent
Protection
24–36 VDC, 8 A, positive or negative,
single source or dual sources
AWG 14 (2.0 mm
2
) AWG 14 (2.0 mm
2
),
minimum
Amp/Tyco No. 32957
or equivalent
20 A
maximum
36–60 VDC, 5 A, positive or negative,
single source or dual sources
Table 2 DC Wiring Requirements for Cisco 2821 and Cisco 2851 Routers
DC Input DC Input Wire Size
Safety Ground Wire
Size Wire Terminal (Lug)
Overcurrent
Protection
24–36 VDC, 12 A, positive or negative,
single source or dual sources
AWG 14 (2.0 mm
2
)AWG 14 (2.0 mm
2
),
minimum
Amp/Tyco No. 32957
or equivalent
20 A
maximum
36–60 VDC, 8 A, positive or negative,
single source or dual sources

Cisco 2800 Series Specifications

General

Power Supply	Internal power supply
Product Type	Router
Form Factor	Rack-mountable
Connectivity Technology	Wired
Power Device	Internal power supply
Operating System	Cisco IOS
Integrated Services	Security, voice
WAN Interfaces	T1/E1, Serial
LAN Interfaces	Fast Ethernet, Gigabit Ethernet
Expansion Slots	4
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network/Transport Protocol	IP, TCP
Remote Management Protocol	SNMP, Telnet
Features	VPN support, Quality of Service (QoS), VLAN support
Voltage Required	AC 100-240 V
Security Features	Firewall, VPN, Access Control Lists (ACLs)
