• ROMMON NVRAM is cleared and returned to default.
• All extra images are removed; the current running image remains.
• FXOS logs, core files, SSH keys, certificates, FXOS configuration, and Apache configuration are
removed.
If power is lost between when you pushed the reset button and when the reset process is complete, the
process stops and you have to push the button again after the system powers back on.
Note
For More Information
• See Remove and Replace the SSD for the procedure for removing a replacing the SSD.
• See Install, Remove, and Replace the Network Module for the procedure for installing network modules.
• See 8-Port 1/10/25-Gb Network Module, on page 15 for more information about the network module.
• See 6-Port 1-Gb SX/10-Gb SR/10-Gb LR/25-Gb SR/25-Gb LR Network Module with Hardware Bypass
, on page 21 for more information about the network module.
• See 8-Port 10/100/1000Base-T Network Module with Hardware Bypass, on page 19 for more information
about the network module.
• See 4-Port 40-Gb Network Module, on page 17 for more information about the network module.
Front Panel LEDs
The following figure shows the Secure Firewall 3100 front panel LEDs.
Figure 6: Secure Firewall 3100 Front Panel LEDs
