Cisco 3105 - Supported SFP;SFP+;QSFP+ Transceivers

Supported SFP/SFP+/QSFP+ Transceivers
The SFP/SFP+/QSFP+ transceiver is a bidirectional device with a transmitter and receiver in the same physical
package. It is a hot-swappable optical or electrical (copper) interface that plugs into the SFP/SFP+/QSFP+
ports on the fixed ports and the network module ports, and provides Ethernet connectivity.
Figure 15: SFP Transceiver
Bail clasp2Dust plug1
Transmit optical bore4Receive optical bore3
Safety Warnings
Take note of the following warnings:
Statement 1055—Class 1/1M Laser
Invisible laser radiation is present. Do not expose to users of telescopic optics. This applies to Class 1/1M
laser products.
Warning
Statement 1056—Unterminated Fiber Cable
Invisible laser radiation may be emitted from the end of the unterminated fiber cable or connector. Do
not view directly with optical instruments. Viewing the laser output with certain optical instruments, for
example, eye loupes, magnifiers, and microscopes, within a distance of 100 mm, may pose an eye hazard.
Warning
Overview
29
Overview
Supported SFP/SFP+/QSFP+ Transceivers
