Figure 4: Example Compliance Label
Chassis serial number2Chassis model number1
—Documentation Portal QR code3
Front Panel
The following figure shows the front panel of the Secure Firewall 3100. See Front Panel LEDs, on page 11
for a description of the LEDs.
