Cisco 3600 Series User Manual

Connecting Digital Modem Network Modules to a Network 10-7
Adding 6-Port MICA Modules to a Digital Modem Network Module
Figure 10-3 6-Port MICA Module
To remove, replace, or install a MICA module, you must first remove the digital modem
module from the router chassis.
Caution To avoid damaging electrostatic discharge (ESD)-sensitive components,
observe all ESD precautions when handling MICA modules. To avoid damaging the
network module or the MICA module, avoid excessive force when you remove or replace
MICA modules.
H10826
Alignment holes
Connector edge
Polarization notchPolarization notch

Cisco 3600 Series Specifications

General

Operating System	Cisco IOS
Series	3600
Type	Modular Router
Interfaces	Ethernet, Fast Ethernet, Serial, ISDN
Routing Protocols	RIP, OSPF, EIGRP, BGP, IS-IS
Redundancy	Optional redundant power supply
Management	CLI, SNMP, Telnet
Weight	Varies depending on the specific model
Power Supply	AC or DC, optional redundant power supply
