8-Port and 16-Port Analog Modem Network Modules
Cisco Network Modules Hardware Installation Guide
11-2
Figure 11-1 8-Port Analog Modem Network Module
Figure 11-2 16-Port Analog Modem Network Module
The following statement applies in Australia:
Warning This equipment will be inoperable when mains power fails.
The following statement applies in New Zealand:
Warning This equipment does not fully meet Telecom’s impedance
requirements. Performance limitations may occur when used in conjunction with
some parts of the network. Telecom will accept no responsibility should
difficulties arise in such circumstances.
H11603
MODEMS
EN
76543210
IN USE
8AM
H11602
MODEMS
EN
76543210
15 14 13 12 11 10 9 8
IN USE
IN USE
16AM
