Cisco 3945 User Manual

118
Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
OL-20696-04
Chapter Configuring Backup Data Lines and Remote Management
Configuring Data Line Backup and Remote Management Through the ISDN S/T Port
7. interface dialer dialer-rotary-group-number
8. ip address negotiated
9. encapsulation encapsulation-type
10. dialer pool number
11. dialer string dial-string# [:isdn-subaddress]
12. dialer-group group-number
13. exit
14. dialer-list dialer-group protocol protocol-name {permit | deny | list access-list-number |
access-group}
DETAILED STEPS
Command Purpose
Step 1
isdn switch-type switch-type
Example:
Router(config)# isdn switch-type basic-net3
Router(config)#
Specifies the ISDN switch type.
The example specifies a switch type used in
Australia, Europe, and the United Kingdom. For
details on other supported switch types, see Cisco
IOS Dial Technologies Command Reference.
Step 2
interface type number
Example:
Router(config)# interface bri 0
Router(config-if)#
Enters configuration mode for the ISDN BRI.
Step 3
encapsulation encapsulation-type
Example:
Router(config-if)# encapsulation ppp
Router(config-if)#
Sets the BRI0 interface encapsulation type.
Step 4
dialer pool-member number
Example:
Router(config-if)# dialer pool-member 1
Router(config-if)#
Specifies the dialer pool membership.
Step 5
isdn switch-type switch-type
Example:
Router(config-if)# isdn switch-type
basic-net3
Router(config-if)#
Specifies the ISDN switch type.
Step 6
exit
Example:
Router(config-if)# exit
Router(config)#
Exits interface configuration mode and enters
global configuration mode.

Cisco 3945 Specifications

General

Form Factor	Rack-mountable
Maximum Throughput	75 Mbps
Product Type	Router
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Operating System	Cisco IOS
Flash Memory	256 MB
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP
Encryption Algorithm	DES, AES
Features	Firewall, VPN, Quality of Service (QoS), VLAN support
Interfaces	2 x USB
Security Features	Intrusion Prevention System (IPS)
Operating Temperature	32 °F to 104 °F (0 °C to 40 °C)
Storage Temperature	-4 °F to 149 °F (-20 °C to 65 °C)
Humidity	10 - 85% (non-condensing)
Memory	2 GB
Expansion Slots	4 (free) x EHWIC ¦ 2 x service module ¦ 1 x ISM ¦ 1 x CompactFlash Card
