Cisco 3900 Series, Cisco 2900 Series, and Cisco 1900 Series Integrated Services Routers Generation 2 Software Configuration Guide
Chapter Configuring Ethernet Virtual Connection Bridge Domain
Connectivity Fault Management (CFM) over EVC BD
Step 4
mep archive-hold-time minutes
Example:
Router(config-ecfm)# mep
archive-hold-time 60
Sets the amount of time that data from a missing MEP is
kept in the continuity check database or that entries are
held in the error database before they are purged.
Step 5
service {ma-name | ma-num | vlan-id
vlan-id | vpn-id vpn-id} [port | vlan
vlan-id [direction down]]
Example:
Router(config-ecfm)# service
Customer1 vlan 101 direction down
Configures an MA within a maintenance domain and
enters CFM service configuration mode.
• If a service is already configured and you configure a
new MA name and also specify the direction down
keyword, a second service is added that maps to the
same VLAN. If you configure a new MA name and
do not specify the direction down keyword, the
service is renamed to the new MA name.
Step 6
continuity-check [interval time |
loss-threshold threshold | static
rmep]
Example:
Router(config-ecfm-srv)#
continuity-check
Enables the transmission of CCMs.
Step 7
continuity-check [interval time |
loss-threshold threshold | static
rmep]
Example:
Router(config-ecfm-srv)#
continuity-check interval 10
Configures the time period between CCM transmissions.
• The values supported are platform dependent.
Step 8
continuity-check [interval time |
loss-threshold threshold | static
rmep]
Example:
Router(config-ecfm-srv)#
continuity-check loss-threshold 10
Sets the number of CCMs that should be missed before
declaring that a remote MEP is down.
Step 9
exit
Example:
Router(config-ecfm-srv)# exit
Returns the device to Ethernet CFM configuration mode.
Step 10
exit
Example:
Router(config-ecfm)# exit
Returns the device to global configuration mode.
Step 11
ethernet cfm global
Example:
Router(config)# ethernet cfm global
Enables CFM processing globally on the device.
Command Purpose

Cisco 3945 Specifications

General

Form Factor	Rack-mountable
Maximum Throughput	75 Mbps
Product Type	Router
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Operating System	Cisco IOS
Flash Memory	256 MB
Network/Transport Protocol	IPSec
Remote Management Protocol	SNMP
Encryption Algorithm	DES, AES
Features	Firewall, VPN, Quality of Service (QoS), VLAN support
Interfaces	2 x USB
Security Features	Intrusion Prevention System (IPS)
Operating Temperature	32 °F to 104 °F (0 °C to 40 °C)
Storage Temperature	-4 °F to 149 °F (-20 °C to 65 °C)
Humidity	10 - 85% (non-condensing)
Memory	2 GB
Expansion Slots	4 (free) x EHWIC ¦ 2 x service module ¦ 1 x ISM ¦ 1 x CompactFlash Card
