Cisco 4321 ISR User Manual

1-43
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of Cisco 4000 Series ISRs
Specifications
The following table provides Cisco 4331 ISR specifications.
Table 1-9 Cisco 4351 ISR Specifications
Description Specification
Physical
Dimensions (H x W x D) 3.5 x 17.25 x 18.7 in. (88.9 x 438.2 x 474.9 mm),
2 RU height
Weight with AC PS (w/o modules) 28.8 lb (13.1 kg)
Weight with one AC 1,100 PS (w/o modules) 30.5 lbs (13.9 kg)
Power
AC input power
• Input voltage 100 to 240 VAC, autoranging
• Frequency 47 to 63 Hz
• Input current 5.3 A
• Input current with PoE Power Adaptor 7.4 A
• Surge current 60 A peak and less than 12 Arms per half cycle
Power consumption 75 to 320 W, 256 to 1092 BTU/hr (configuration
dependent)
• With AC-PoE 80 to 750 W, 273 to 2560 BTU/hr (configuration
dependent)
Ports
Console port One RJ-45 connector and one mini USB Type B,
USB 2.0 compliant
Auxiliary port RJ-45 connector
USB ports Two USB Type A, USB 2.0 compliant, 2.5 W (500
mA) max
1
1. 480 Mb/s individually; bandwidth is shared when both are used.
10/100/1000 Gigabit Ethernet Three RJ-45 connectors (GE0/0/0, GE0/0/1,
GE0/0/2), auto-MDIX
SFP Manual configuration is required to switch
between the RJ-45 and the SFP module.
Table 1-10 Cisco 4331 ISR Specifications
Description Specification
Physical
Dimensions (H x W x D) 1.75 x 17.25 x 17.25 in. (44.45 x 438.2 x 438.2
mm)
Weight with one AC PS (w/o modules) 13.50 lb (6.12 kg)
Power
AC input power
