Cisco Communication Media Module for Catalyst 6500 Series Switch and Cisco 7600 Series Router Installation and Verification Note
6-Port T1 and E1 Port Adapters
The front panel features of the 6-port T1 and E1 port adapters are as follows:
• Receive port LEDs—The LEDs on the front panel indicate the status of each T1 and E1 interface.
Table 3 describes the receive port LED operation.
• RJ-45 connectors—See the “RJ-45 Port Connector and Cabling Specifications” section on page 25
for details.
Figure 2 shows the front panels of the 6-port T1 and E1 port adapters.
Table 2 Rear Module STATUS LED
Color Description
Green Port adapter in slot 4 is up and operational.
Red Port adapter in slot 4 is shut down.
No light Slot 4 port adapter is not located by the system.
