Cisco 7609 Installing

Chapter 3 Installing the Cisco 7609 Internet Router
Installing the Stabilizer Kit
3-10
Cisco 7609 Internet Router Installation Guide
OL-5079-04
Installing the Stabilizer Kit
Note The stabilizer kit is included only in the accessory kits for the Cisco 7609
Internet Router.
If you are not installing the Cisco 7609 Internet Router in a rack, you must install
stabilizer brackets to the bottom of the chassis. The stabilizer brackets reduce the
possibility that the freestanding chassis will tip over.
Open the stabilizer kit package and use the kit contents list in Table 3-2 to verify
that all parts are included.
Note Have a second person available to perform this procedure.
To install the stabilizer brackets, perform these steps:
Step 1 Have one person tilt and hold the chassis to one side.
Step 2 With the chassis tilted, attach the stabilizer bracket to the side of the chassis with
the eight M4 screws as shown in Figure 3-5.
Table 3-2 Stabilizer Kit Contents
Quantity Part Description Received
16 M4 Phillips countersunk-head screws
2 Stabilizer brackets

Cisco 7609 Specifications

General

Chassis Slots	9
Switch Fabric Capacity	720 Gbps
Power Supply Options	AC or DC
Product Type	Router
Form Factor	Rack-mountable
Supported Line Cards	Various Cisco 7600 Series line cards
Operating System	Cisco IOS
Management	CLI, SNMP
Forwarding Performance	400 Mpps
Maximum Power Consumption	4000 Watts
Redundancy	Yes
Interfaces/Ports	Various, depending on line cards installed
