Cisco 7916 Phone Guide

10
Figure 4 Connecting the Expansion Module to the
Support Bar
1
Open slots on the Cisco Unified IP Phone
Expansion
Module 7916
2
Hooks on the support bar
3
Thumbscrews
Step 1 Position the phone so that the front of the phone is
facing up.
Step 2 Line up the two open slots on the bottom of the
Cisco
Unified IP Phone Expansion Module 7916 with
the two hooks on the support bar.

Cisco 7916 Specifications

General

Brand	Cisco
Model	7916
Category	Telephone Accessories
Language	English
