4-20
Cisco 850 Series and Cisco 870 Series Access Routers Hardware Installation Guide
OL-5331-01
Chapter 4 Router Cabling Procedures
Connecting a G.SHDSL Line
Figure 4-16 Connecting the G.SHDSL Line
Caution Cisco Systems DSL WAN Interfaces are tested for compliance with regulatory standards such as FCC
Part 68, ITU-T K.21, IEC 61000-4-5, and CSA/EN/IEC/UL 60950-1. These standards assume Primary
Protection devices protect the Customer Premise Equipment (CPE). These devices are normally
installed by the service provider, local exchange carrier or qualified service person and are located at the
telecom service provider entrance, network interface box, or demarcation point. See
Figure 4-17 for the
likely location of the primary protection device. The primary protection device must be suitable for the
xDSL interface employed.


Please contact your sales team or qualified service person for further information and installation.
1 G.SHDSL port on the router 2 DSL wall jack
117967
LE
FT
R
IG
H
T / P
R
IM
A
R
Y
G
.S
H
D
S
L
IS
D
N
S
/T
L
A
N
F
E
0F
E
1
F
E
2
F
E
3
Cisco 878W
C
O
N
S
O
L
E
A
U
X
R
E
S
E
T
+
5,+1
2 V
D
C
3
2
1
