1-62
Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
Figure 1-39 shows the back panel of the Cisco C887VA Router.
Figure 1-39 Back Panel of the Cisco C887VA Router
For information on installing Cisco C880 series routers, see the following link:
http://www.cisco.com/en/US/docs/routers/access/800/860-880-890/hardware/installation/guide/2Instal
l880-860.html
Cisco C887VAM Router
Figure 1-40 shows the front panel of the Cisco C887VAM router:
Figure 1-40 Front Panel of the Cisco C887VAM Router
For detailed description about LEDs on Cisco C880 series router, see “LEDs” section on page 1-23.
361131
0
CiscoCisco 887887VA
VDSL/ADSLVDSL/ADSL
over POTSover POTS
FE LANFE LAN
3 2 1 0
CONSOLE
CONSOLE
AUXAUX
12VDC 2.2.5-5A-5A
(POE)(POE)
RESETRESET
21 3 4 5 7 8 9
6
1 Primary WAN port—VDSL/ADSL over
POTS
6 Reset button
2 USB port 7 Power connector
3 4-port 10/100 Ethernet switch 8 Earth ground connection
4 Serial port—console or auxiliary 9 Kensington security slot
5 On/Off switch
361132
CiscoCisco
800
Series
OKOK
POEOE
PPPPPP
FE FE LA N
VPN
0
1 2
3
0 1
CD
CD DATA
xDSL
xDSL
1
1 LEDs
