Cisco 890 Series Installation Guide

A-27
Cisco Integrated Services Router Hardware Installation Guide
OL-27407-02
Appendix A Technical Specifications
Cisco 860, 880, 890 Series
Voice ISDN BRI Interface Pin Numbers and Functions
Table A-27 lists the interface pin numbers and functions for the voice ISDN BRI port.
SFP Port Connector Pinouts
Table A-28 lists the pinouts for the SFP port.
7Unused
8Unused
Table A-26 Data BRI Port Pinouts (continued)
Pin Function
Table A-27 Interface Pin Numbers and Functions
ISDN BRI NT/TE Card NT Interface
1
1. Use a straight-through cable for NT interfaces.
TE Interface
2
2. Use a crossover cable for TE interfaces.
Pin 3/T+ Pin 3/R+ Pin 3/T+
Pin 4/R+ Pin 4/T+ Pin 4/R+
Pin 5/R- Pin 5/T- Pin 5/R-
Pin 6/T- Pin 6/R- Pin 6/T-
Table A-28 SFP Port Pinouts
Pin Function
1 TX Ground
2TX Fault
3TX disable
4 Module definition 2
5 Module definition 1
6 Module definition 0
7 Rate Select
8 Loss of signal
9 Receiver ground
10 Receiver ground
11 Receiver ground
12 Inverted received data out
13 Received data out
14 Receiver ground
15 Receiver power

Cisco 890 Series Specifications

General

Product Type	Router
Form Factor	Desktop
USB Ports	1 x USB 2.0
Firewall	Yes
VPN Support	Yes
RAM	256 MB
Wireless	802.11n
Operating Temperature	32°F to 104°F (0°C to 40°C)
Operating Humidity	10 to 85% non-condensing
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Network / Transport Protocol	TCP/IP
Routing Protocol	OSPF, BGP, RIP-1, RIP-2, EIGRP, HSRP, VRRP
Remote Management Protocol	SNMP, Telnet, HTTP, HTTPS, SSH
Features	VPN support, firewall protection, Quality of Service (QoS), VLAN support
Encryption Algorithm	AES, 3DES, DES
