2-45
Cisco Integrated Services Router Hardware Installation Guide
Chapter 2 Installing the Router
Installing the Cisco 860, 880, 890 ISR
Step 3 Hang the router on the screw without forcibly pushing towards the wall side. The screw head may
damage the protection wall inside. Place the power adapter on a nearby horizontal surface. See
Figure 2-42.
Figure 2-42 Router Mounted on the Wall
Step 4 Connect the chassis to a reliable earth ground. For the chassis ground connection procedures, see the
“Installing Cisco 890 Series in a Rack” section on page 2-54.
1 Two number-10 wood screws mounted on the
wall
3 Horizontal surface on which to place the
power adapter
2 Wall-mount holes 4 Distance between the screw head and the wall,
1/8 in. (0.32 cm)
231982
4
2
1
1
3

Cisco 892FSP Specifications

General

Product Type	Router
Form Factor	Desktop
Console Ports	1 x RJ-45
Connectivity Technology	Wired
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
RAM	512 MB
Flash Memory	256 MB
Power Device	Internal power supply
Ports	8 x LAN, 1 x WAN, 1 x USB, 1 x Console
Wireless	No
Operating System	Cisco IOS
WAN Ports	1 x 10/100/1000Base-T
LAN Ports	8
Security Features	Firewall, VPN support, IPSec, SSL, 3DES, AES
Routing Protocols	BGP, OSPF, EIGRP, RIP
Network / Transport Protocol	IPSec
Remote Management Protocol	SNMP, Telnet, SSH, HTTP, HTTPS
Features	Quality of Service (QoS), VLAN Support, DHCP Server, NAT, IPv6 Support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Voltage Required	AC 120/230 V (50/60 Hz)
Interfaces	8 x LAN - RJ-45, 1 x WAN - RJ-45, 1 x Console - RJ-45
