Connecting T3 DFC on Cisco AS5400 to T3 CSU/DSU
• Connect a synchronous serial port to a modem or a CSU/DSU with a serial transition cable.
Connecting Serial Port on Cisco AS5350 to CSU/DSU
62178
T3 CSU/DSU
T3 DFC
T3 cables
BNC connectors
35675
Serial
transition
cable
CSU/DSU or
other DCE or DTE
Synchronous serial
port (DB-26)
EIA/TIA-232, EIA/TIA-449, EIA/TIA-530A,
EIA/TIA-530, V.35, or X.21 connector
Internet
