Cisco AS5400 - Page 29

29
Cisco AS5350 DC Power Supply Connections—Redundant Power Supply
Cisco AS5400 DC Power Supply Connections
Step 3 Strip off a quarter of an inch (1/4 in. [0.625 cm]) of insulation on the safety ground, 48 VDC Return, and -48 VDC
input wires.
A- A+
B- B+
82637
Power switch
Source A - NEG
Source A - RTN
Source B - NEG
Source B - RTN
Ground
To DC source
DC connector
On/off
switch
LEDs
31628
Terminal
block
Mounting screwMounting screw
Mounting
screw
IN OK
DC OK
OTF
IN OK
DC OK
OTF
LEDs
Terminal
block
Strain-relief
clamps
Strain-relief
clamps
