Step 4 Specify the T1 controller you want to configure.
Note The CT1/E1 controller numbering convention is dfc-slot/port in CLI commands. DFC slot numbering starts from the
motherboard and works up from left to right. Slot 0 is reserved for the motherboard. The DFC slots are numbered
sequentially from 1 to 3 for the Cisco AS5350 and 1 to 7 for the Cisco AS5400. Port numbering is from 0 to 7,
depending on the trunk DFC installed.
The CT3 controller numbering convention is dfc-slot/port in CLI commands. DFC slot numbering starts from the
motherboard and works up from left to right. Slot 0 is reserved for the motherboard. The DFC slots are numbered
sequentially from 1 to 3 for the Cisco AS5350 and 1 to 7 for the Cisco AS5400. Port number value is always 0
. Under
the CT3, the CT1 controller numbering convention is dfc-slot/port:channel in CLI commands. Channel values range from
1 to 28. For illustrations showing the slot locations, see the “Slot Numbering” section on page 59
Gateway(config)# controller t1 1/0
or
Gateway(config)# controller t3 7/0:16
or
Specify the E1 controller you want to configure.
Gateway(config)# controller e1 1/0
Note When you configure the CT1or CE1 controller, a corresponding D-channel serial interface is created automatically.
Step 5 Specify the PRI channels:
Gateway(config-controller)# pri-group [timeslots range]
Note For CT1 ISDN PRI—If you do not specify the time slots, the specified controller is configured for 23 B channels and 1
D channel. B channel numbers range from 1 to 23; channel 24 is the D channel for T1. Corresponding serial interface
numbers range from 0 to 23. In commands, the D channel is interface serial
slot/port:23—for example, interface serial
1/0:23.
ISDN Switch Types
Area Keyword Switch Type
Australia primary-ts014 Australia PRI switches
Europe primary-net5 European, New Zealand, and Asia ISDN PRI
switches (covers the Euro-ISDN E-DSS1
signaling system and is European
Telecommunication Standards Institute or
ETSI-compliant)
Japan primary-ntt Japanese ISDN PRI switches
None none No switch defined
North America primary-4ess AT&T 4ESS switch type for the United States
primary-5ess AT&T 5ESS switch type for the United States
primary-dms100 NT DMS-100 switch type for the United States
primary-ni National ISDN switch type
