Cisco ASA 5506-X Hardware Installation Guide

CHAPTER 1
Overview
This chapter describes the hardware features of the Cisco ASA 5506-X series of security appliances, and
contains the following sections:
•
About the ASA 5506-X, ASA 5506W-X, and ASA 5506H-X, page 1
•
Package Contents, page 4
•
Front Panel, page 5
•
Rear Panel, page 6
•
LEDs, page 8
•
Network Ports, page 11
•
Console Ports, page 11
•
Internal and External Flash Storage, page 12
•
Solid State Drive, page 12
•
Power Supply Modules, page 13
•
Hardware Specifications, page 13
•
Power Cord Specifications, page 14
About the ASA 5506-X, ASA 5506W-X, and ASA 5506H-X
The Cisco ASA 5506-X, ASA 5506W-X, and ASA 5506H-X adaptive security appliances are part of the ASA
5500-X of next-generation mid-range ASAs and are built on the same security platform as the rest of the ASA
family.
Your ASA 5506-X ships with either ASA or Firepower Threat Defense software preinstalled. To reimage
your device, see Reimage the Cisco ASA or Firepower Threat Defense Device.
Note
This next-generation ASA delivers unprecedented levels of defense against threats to the network with deeper
web inspection and flow-specific analysis, improved secure connectivity via end-point security posture
Cisco ASA 5506-X, ASA 5506W-X, and ASA 5506H-X Hardware Installation Guide
Online Only 1

Cisco ASA 5506-X Specifications

General

Model	ASA 5506-X
Firewall Throughput	750 Mbps
Maximum Firewall Connections	50, 000
Maximum VPN Peers	50
Integrated Ports	8 x 1 GE
Stateful Inspection Throughput	750 Mbps
Weight	4.4 lb (2 kg)
Firewall Throughput (Multiprotocol)	750 Mbps
Firewall Throughput (Application Visibility and Control AVC)	250 Mbps
Concurrent Sessions	50, 000
New Connections per Second	10, 000
IPsec VPN Throughput	100 Mbps
Interfaces	8 x 1 GE
Memory	4 GB
Flash Memory	8 GB
Form Factor	Desktop
VPN Throughput	100 Mbps
Maximum Concurrent Sessions	50, 000
New Sessions per Second	10, 000
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-13 to 158°F (-25 to 70°C)
Power Supply	External
Humidity	10% to 90% non-condensing
