Status LEDs
The locations and meanings of the
status LEDs are described in LEDs, on
page 8.
2Power cord socket.
The chassis power-supply socket. See
Power Supply Modules, on page 13
for more information about the chassis
power supply.
The ASA is powered on when
you plug in the AC power
supply.
Note
1
Management port
A Gigabit Ethernet interface restricted
to network management access only.
Connect with an RJ-45 cable.
4Network data ports
Four Gigabit Ethernet RJ-45 (8P8C)
network I/O interfaces. The ports are
numbered (from top to bottom) 1, 2, 3,
4,. Each port includes a pair of LEDs,
one each for connection status and link
status. The ports are named and
numbered Gigabit Ethernet 1/1 through
Gigabit Ethernet 1/4. See Network
Ports, on page 11 for additional
information.
3
USB port
A standard USB Type A port is
provided that allows the attachment of
an external device, such as mass
storage. See Internal and External Flash
Storage, on page 12 for additional
information.
6Console ports
Two serial ports, a standard RJ-45
(8P8C), and a mini USB Type B, are
provided for management access via
an external system. See Console Ports,
on page 11 for additional information.
5
Reset button
A small recessed button that if pressed
for longer than three seconds resets the
ASA to its default “as-shipped” state
following the next reboot.
Configuration variables are reset to
factory default. However, the flash is
not erased and no files are removed.
You can use the service
sw-reset-button to disable the
reset button. The default is
enabled.
Note
7
LEDs
Facing the rear of the ASA 5506-X and ASA 5506W-X chassis, the LEDs are located on the top left edge
(facing the front of the chassis, they are in the back right corner of the top). Facing the rear of the ASA
Cisco ASA 5506-X, ASA 5506W-X, and ASA 5506H-X Hardware Installation Guide
8 Online Only
