Cisco ASA 5506-X - Configure the Wireless Access Point (ASA 5506 W-X); Procedure

Power cord4Power cord retention lock3
Power supply5
Front Panel
The following figure shows the front panel of the ASA 5506-X. The ASA 5506W-X has an identical front
panel. Note that there are no connectors or LEDs on the front panel.
Figure 3: 5506-X and 5506W-X Front Panel
The following figure shows the front panel of the ASA 5506H-X. Note that there are no connectors or LEDs
on the front panel.
Figure 4: 5506H-X Front Panel
Cisco ASA 5506-X, ASA 5506W-X, and ASA 5506H-X Hardware Installation Guide
Online Only 5
Overview
Front Panel
