Cisco ASR 903 Troubleshooting

MeaningColor/StateLED Label
FailureRedOperating Status (STAT)
Booting (if IM has a local CPU)Yellow
OperationalGreen
No PowerOff
At least one of the 4 ports is in an
up state.
Green68-Pin Connector LEDs
At least one of the 4 ports is
passing traffic
Blinking Green
All four ports are successfully
initialized and in a down state
Solid Yellow
At least one of the port has failedBlinking Yellow
All the ports are not enabled (at
POR)
Off
Port is passing trafficGreen12-in-1 Connector LEDs
Port successfully initialized and in
a down state
Solid Yellow
Port has failedBlinking Yellow
Not Enabled (at POR)Off
E and M Interface Module LEDs
The table below summarizes the LEDs for the E & M interface module.
Table 26: Cisco ASR 903 Router EandM IM LEDs
DescriptionColor/StateLED Label
All power rails are within spec.GreenPower (PWR)
DisabledRed
No PowerOff
Cisco ASR 903 Aggregation Services Router Hardware Installation Guide
25
Troubleshooting
Interface Module LEDs
