Cisco ASR 920 series Installing Guide

Connect to the EIA Console Port
The US-to-RJ45 adapter cable and the DB9 console cable are not included with the router; they can be
ordered separately from Cisco.
Note
The serial console cable kit is not included with the router; it is ordered separately.Note
To connect a terminal to the EIA Console port on the router, follow these steps:
Step 1
Connect the USB end of the USB-to RJ-45 cable to the EIA Console port.
Step 2
Connect the RJ-45 end of the DB-9 adapter cable to the USB-to RJ-45 cable, as shown in the figure below.
Figure 24: EIA Console Port
Cisco ASR 920 Series Aggregation Services Router Hardware Installation Guide
37
Installing the Cisco ASR 920 Series Router
Connect to the EIA Console Port

Cisco ASR 920 series Specifications

General

Form Factor	1RU
Operating System	Cisco IOS XE
Model	ASR 920 series
Memory	4 GB DRAM
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
MTBF	Varies by model
Management	CLI, SNMP
