If the chassis is mounted using 19-inch brackets, you must assemble the cable guides before installing the
chassis on the rack.
Note
To install the cable guides, perform these steps:
SUMMARY STEPS
1. Position the cable guide-left and cable guide-right against the front of the chassis and align the four screw
holes, as shown in the fgure below.
2. Secure the cable guides with the four M6x12mm screws supplied with the cable kit. The recommended
maximum torque is 3N-m.
DETAILED STEPS
Step 1 Position the cable guide-left and cable guide-right against the front of the chassis and align the four screw holes, as shown
in the fgure below.
Figure 6: Cable Guide Installation For 19-inch Rack Brackets
Installing the Cisco ASR 920 Series Router
7
Installing the Cisco ASR 920 Series Router
Attaching the Cable Guides
