A-9
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Appendix A Technical Specifications
Table A-12 lists the DC electrical specifications for the Cisco ASR 9010 Router.
Table A-13 lists the DC electrical specifications for the Cisco ASR 9006 Router.
Table A-12 Cisco ASR 9010 Router DC Electrical Specifications
Description Value
Power modules per system Version 1 power system
Up to six DC power modules per system, three per tray
Version 2 power system:
Up to eight DC power modules per system, four per tray
Total DC input power per
power module
Ve r s io n 1 :
1700 W (1500 W output module)
Ve r s io n 2 :
2300 W (2100 W output module)
Rated input voltage per
power module
–48 VDC nominal in North America
–60 VDC nominal in the European Community
(Range: –40.5 to –72 VDC [–75 VDC for 5 ms])
Input current draw
1
1. For each DC power supply module. Some power/chassis configurations may operate at lower current ratings than those
specified in this table. Contact your Cisco technical representative for more information.
49 A maximum at –48 VDC nominal
39 A maximum at –60 VDC nominal
Source DC service
requirement
1
Sufficient to supply the rated input current. Local codes apply.
Redundancy At least four DC power modules (two per power tray) are required for
N+1 redundancy for a fully configured system (version 1 and
version 2).
Table A-13 Cisco ASR 9006 Router DC Electrical Specifications
Description Value
Power modules per system Version 1 power system
Up to three DC power modules per system
Version 2 power system:
Up to four DC power modules per system
Total DC input power per
power module
Version 1 power system
1700 W (1500 W output module)
Version 2 power system
2300 W (2100 W output module)
Rated input voltage per
power module
–48 VDC nominal in North America
–60 VDC nominal in the European Community
(Range: –40.5 to –72 VDC [–75 VDC for 5 ms])
Input current draw
1
49 A maximum at –48 VDC nominal
39 A maximum at –60 VDC nominal
