Chapter 2 Functional Description
Ethernet Line Cards
2-port 100-Gigabit Ethernet Line Card
The 2-port 100-GE line card provides two CFP cages for CFP Ethernet optical interface modules that
operate at a rate of 100-Gbps.
The two CFP modules can be100-Gigabit Ethernet multimode connections.
The 2-port 100-GE line card is available in either an -SE (Service Edge Optimized) or -TR (Packet
Transport Optimized) version. Both versions are functionally equivalent, but vary in configuration scale
and buffer capacity.
Each CFP cage on the 2-port 100-GE line card has an adjacent Link LED visible on the front panel. The
Link LED indicates the status of the associated CFP port.
Figure 2-32 shows the front panel and connectors of the 2-port 100-GE line card.
1 Ejector lever (one of two) 6 Port 23 SFP+ cage
2 Captive installation screw (one of two) 7 Port 24 SFP+ cage
3 Port 0 SFP+ cage 8 Port 35 SFP+ cage
4 Port 11 SFP+ cage 9 Line Card Status LED
5 Port 12 SFP+ cage
