Cisco ATA 186 Installation And Configuration Guide

2-9
Cisco ATA 186 Installation and Configuration Guide
OL-1267-01
Chapter 2 Installing the Cisco ATA 186
Installation Warnings
Installing the Cisco ATA 186
Follow these steps to install the Cisco ATA 186 hardware. (See Figure 2-2.)
Figure 2-2 Installing the Cisco ATA 186
Advarsel
Utstyret er utfomet til bruk med TN-strømsystemer.
Aviso
O dispositivo foi criado para operar com sistemas de corrente TN.
¡Advertencia!
El equipo está diseñado para trabajar con sistemas de alimentación
tipo TN.
Varning!
Enheten är konstruerad för användning tillsammans med
elkraftssystem av TN-typ.
10BaseT ACT 5VPHONE 1 PHONE 2
62290
A
B
C D

Cisco ATA 186 Specifications

General

Operating Temperature	32°F to 104°F (0°C to 40°C)
Protocol	SIP, H.323
Network Interface	10/100BASE-T Ethernet
Audio Codec Support	G.729a, G.723.1
Power Supply	5V DC
Weight	0.23 kg (0.5 lb)
Relative Humidity	10 to 90% noncondensing
Ports	2 RJ-11 FXS ports
