Page #6 background imageLoading...
Page #6 background image
Mount Your ATA
You can place the ATA on a desktop or mount it on a wall.
To prevent the ATA from overheating, do not operate it in an area that exceeds an ambient temperature of
104°F (40°C).
Caution
Desktop Placement
Place the ATA on a flat surface near an electrical outlet.
Do not place anything on top of the ATA; excessive weight could damage it.
Warning
Wall Mounting
The ATA has two wall-mounted slots on the bottom panel. To mount the ATA on a wall, you need mounting
hardware (not included). Suggested hardware is illustrated (not true to scale).
Recommended hardware (not included): Two #6 pan head, 5/8 in., self-tapping screws with anchors for
sheet rock installation.
Get Started with Your New ATA
6
Get Started with Your New ATA
Mount Your ATA

Table of Contents

Other manuals for Cisco ATA 191

Preview: User Guide
User Guide40 pages
Preview: Administration Guide
Administration Guide142 pages
Preview: Manual
Manual10 pages
Preview: Quick Start Guide
Quick Start Guide12 pages
Preview: Setup Guide
Setup Guide6 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco ATA 191 and is the answer not in the manual?

Cisco ATA 191 Specifications

General IconGeneral
Fax SupportT.38 Fax Relay
Relative Humidity10% to 90% (non-condensing)
Ports2 FXS ports
Voice ProtocolSIP
ProtocolsSIP, RTP, RTCP
Power5V DC
Network Interfaces10/100BASE-T Ethernet port
Operating Temperature32°F to 104°F (0°C to 40°C)
Audio CodecsG.711 (a-law and μ-law), G.729a, G.722, G.726
Voice CodecsG.711 (a-law and μ-law), G.729a, G.722, G.726
Storage Temperature14 to 140°F (-10 to 60°C)
