Figure 15: Sliding the Retainer Through the Latch
Latch3AC power cord1
Smaller sleeve for thin
power cords
2
Step 4 Slide the retainer through the other latches to lock it.
Figure 16: Locking the Retainer
Latches3AC power cord1
Sleeve for thin power
cords
2
