Cisco C1111-4PLTEEA - Model-Specific LED Indicators

Figure 24: Cisco 1121-4Px LED Indicators
PoE LED2VPN1
Ethernet Switch Ports 0-34Status3
GE 0/0/1 LED6GE 0/0/0 RJ45 LED5
Micro USB Console LED8GE 0/0/0 RJ45 LED7
USB LED9
Figure 25: Cisco 1121-4PLTEP LED Indicators
PoE LED2VPN1
Ethernet Switch Ports 0-34Status3
GE 0/0/1 LED6GE 0/0/0 RJ45 LED5
Micro USB Console LED8GE 0/0/0 RJ45 LED7
USB LED9
