Figure 47: Chassis Ground Connection-Cisco 111x
Screw (UNC 6-32)1
Ground Lug2
Figure 48: Chassis Ground Connection-Cisco 1101-4PLTEP
Screw (UNC 6-32)1
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
46
Install and Connect the Router
Chassis Grounding
