Cisco C1111x-8P User Manual

You can install external modules before or after mounting a router. However, if you choose to install the
external modules after mounting the router on the rack or wall, ensure that you have optimal access to the
back/front panel of the router.
For information on modules and Field Replaceable Units (FRUs), see the Install and Upgrade Modules and
FRUs section.
Note
Depending on the model, the available options for mounting a Cisco 1000 Series Integrated Services Router
are:
Table 7: Models and Mounting Options
Mounting OptionsModel
Desktop, Rack Mount, Wall Mount using Key-hole Slots, Wall Mount
using-Din-Rail
C111x and C1111X
Desktop, Wall Mount using Key-hole SlotsC1101-4P
Desktop, Wall Mount using Key-Hole SlotsC1101-4PLTEPWx
Desktop, Wall Mount using Key-Hole Slots,C1109-2PLTExx
Desktop, Rack Mounting using Din-Rail Brackets, Under DeskC1121-4Px
Desktop, Rack Mounting using Din-Rail Brackets, Under DeskC1126(X)-8PLTEP
Desktop, Rack Mounting using Din-Rail Brackets, Under DeskC1128(X)-8PLTEP
If you choose to setup the router on a desktop, you can place the router on a desktop, bench top or on a shelf.
Rack Mount
Secure the rack mounting brackets on the sides of the chassis. You must first secure rack mounting brackets
on the chassis before you set up the chassis on the rack.
Do not stack multiple Cisco 1000 Series Integrated Services Routers when mounting the routers on a table
top.
Caution
When mounting Cisco 1000 Series Integrated Services Routers on a rack, ensure that there is ample surrounding
space. This ensures more heat removal, which in turn helps the surrounding air temperature to stay within the
specified operating conditions.
Note
Attach the Brackets for C111x
This procedure describes how to attach the brackets on the router chassis:
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
32
Install and Connect the Router
Rack Mount

Cisco C1111x-8P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Frequency range	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.1Q, IEEE 802.1ag
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB version	3.2 Gen 1 (3.1 Gen 1)
Ethernet LAN (RJ-45) ports	8
Installed SFP modules quantity	4
Fast Ethernet (copper) ports quantity	1
Power over Ethernet (PoE) ports quantity	6
Security algorithms	3DES, 128-bit AES, 256-bit AES, DES
Authentication method	RSA (748/1024/2048 bit), ECDSA (256/384 bit); Integrity: MD5, SHA, SHA-256, SHA-384, SHA512
Routing protocols	VRRP
Data link protocols	HDLC
Supported protocols	IPv4, IPv6, RIP, RIPv2, OSPF, EIGRP, BGP, IS-IS, IGMPv3, PIM SM, SSM, RSVP, ERSPAN, IPSLA, EEM, IKE, ACL, EVC, DHCP, FR, DNS, LISP, HSRP, RADIUS, AAA, AVC, DVMRP, MPLS, IPsec, L2TPv3, BFD
Switching protocols	RFC 2338
IPv4 & IPv6 features	Dual stack IPv4/IPv6
Supported network protocols	ACL, NAT, QoS, BFD, VRF Lite, IP SLA
Antenna type	External
Antennas quantity	2
Product color	Gray
LED indicators	Link, Status
Country of origin	Czech Republic
Flash memory	4000 MB
Certification	UL 60950-1.and EN 60950-1. CAN/CSA C22.2 No. 60950-1. CB to IEC 60950-1, 2
Internal memory type	DRAM
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC, PoE
AC input frequency	50 - 60 Hz
Power consumption (typical)	66 W
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-4 - 149 °C
Operating temperature (T-T)	32 - 104 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Package type	Box
Package depth	508 mm
Package width	342.9 mm
Package height	162.052 mm
Package weight	3455.78 g
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	244 mm
Width	323 mm
Height	44 mm
Weight	1940 g
