Figure
52:
Console
Adapter
for
C1101-4PL
TEP
Micro
USB
to
RJ45
console
adapter
1.
Figure
53:
Console
Adapter
for
C1127X-8PL
TEP
Micro
USB
to
RJ45
console
adapter
1.
Hardware
Installation
Guide
for
the
Cisco
1000
Series
Integrated
Services
Router
50
Install
and
Connect
the
Router
Connect
the
Router
to
a
Console
55
57
